產品特點

Thorlabs的熱釋電能量計探頭用于探測能量10 μJ到15 J的脈沖源。所有這些探頭在185 nm到25 μm波長范圍內提供平坦響應，除了ES4xxC探頭，其范圍從185 nm至2.5 μm

詳細介紹

高速熱釋電能量探頭

重復頻率高達10 kHz的測量
兩種膜層選項：

寬帶黑膜，185 nm到25 μm范圍內具有平坦響應
金屬膜，185 nm到2.5 μm，可用于重復頻率高達10 kHz的探測

有源區?8 mm或?12 mm
BNC接頭，用于示波器
附帶C系列接頭轉接件，用于兼容的Thorlabs表頭(見下表或表頭選擇標簽)

這些高速熱釋電探頭用于測量重復頻率高達10 kHz的脈沖相干和非相干光源。熱釋電探頭不適用于連續光測量，因為熱釋電探頭是將能量從光脈沖轉換為電壓脈沖。ES3xxC探頭具有寬帶黑膜，在185 nm到25 μm范圍內提供平坦響應，并且根據有源區尺寸，可用于重復頻率高達1 kHz的測量。E4xxC探頭具有金屬膜，用于重復頻率高達10 kHz的探測，但提供較短的波長范圍185 nm - 2.5 μm。探頭可選?8 mm或?12 mm傳感區域，且每個輸入孔徑具有SM1(1.035"-40)外螺紋以兼容我們的SM1螺紋透鏡套筒。探頭可以通過BNC接頭直接連接到具有1 MΩ輸入電阻的示波器；將這些探頭與不同負載電阻一起使用可能會降低速率。每個能量探頭都附帶一個BNC轉C系列轉接件，其中包含可追溯至NIST和PTB校準數據。

Thorlabs為這些能量探頭提供重新校準服務，請在下方訂購(型號CAL-THPY)。

Item #a	ES308C	ES312C	ES408C	ES412C
Sensor Image (Click the Image to Enlarge)
Input Aperture Size	?8 mm	?12 mm	?8 mm	?12 mm
Wavelength Range	0.185 - 25 μm		0.185 - 2.5 μm
Energy Range	500 μJ - 1 J	100 μJ - 1 J	100 μJ - 1 J	50 μJ - 500 mJ
Max Repetition Rateb	1 kHz	250 Hz	10 kHz	2 kHz
Max Power Density (Pulse Width)	8 MW/cm2 (10 ns Pulse)		5 MW/cm2 (10 ns Pulse)
Max Pulse Energy Density (Pulse Width)	80 mJ/cm2 (10 ns Pulse)		50 mJ/cm2 (10 ns Pulse)
Coating (Click for Plot)	Black Broadband		Metal
Resolution	5 μJ	1 μJ	1 μJ	1 μJ
Linearity	±1%
Measurement Uncertainty	±5% @ 0.185 - 25 μm		±5% @ 0.185 - 2.5 μm
Housing Dimensionsc	?38 mm x 15 mm	?38 mm x 15 mm	?38 mm x 15 mm	?38 mm x 15 mm
Active Detector Area	50.3 mm2	113.1 mm2	50.3 mm2	113.1 mm2
Cable Length	1.5 m (60")
Post Mounting	8-32 and M4 Combi Mounting Thread
Aperture Thread	External SM1 (1.035"-40) Thread Thread Depth: 3.0 mm (0.12")
Compatible Consoles	PM400, PM100D, and PM5020		PM5020	PM400, PM100D, and PM5020
Compatible Interfaces	PM103, PM103A, PM103E, PM103U, and PM100USB		PM103, PM103A, PM103E, and PM103U	PM103, PM103A, PM103E, PM103U, and PM100USB

完整的規格請查看規格標簽。
@ 1 MΩ負載電阻
包含SM1螺紋深

規格

Item #	ES111C	ES120C	ES145C	ES220C	ES245C
Technical Specs
Detector Type	Standard Pyroelectric Energy Sensor			High-Energy Pyroelectric Energy Sensor
Wavelength Range	185 nm - 25 μm			185 nm - 25 μm
Optical Energy Range	10 μJ - 150 mJ	100 μJ - 500 mJ	500 μJ - 2 J	500 μJ - 3 J	1 mJ - 15 J
Max Repetition Rate (@ 1 MΩ Load)	40 Hz	30 Hz	30 Hz	30 Hz	30 Hz
Max Power Density (Pulse Width)	8 MW/cm2 (10 ns Pulse)			65 MW/cm2 (7 ns Pulse @ 355 nm)
Max Pulse Energy Density (Pulse Width)	0.15 J/cm2 (1 μs Pulse)			0.45 J/cm2 (7 ns Pulse @ 355 nm)
Max Average Power	0.15 W	0.15 W	0.5 W	5 W	10 W
Resolution	100 nJ	1 μJ	1 μJ	25 μJ	50 μJ
Linearity	±1%			±1%
Measurement Uncertainty	±5% @ 190 nm - 25 μm	±5% @ 185 nm - 25 μm	±5% @ 185 nm - 25 μm	±5% @ 185 nm - 25 μm
Thermal Time Constant	20 ms			20 ms

General Information
Coating	Black Broadband			Ceramic
Cooling	Convection			Convection
Compatible Consoles	PM100D, PM400 and PM5020			PM100D, PM400 and PM5020
Compatible Interfaces	PM103, PM103A, PM103E, PM103U, and PM100USB			PM103, PM103A, PM103E, PM103U, and PM100USB
Mechanical Specs
Sensor Dimensions	?36 mm x 16 mm	?50 mm x 18 mm	?75 mm x 21 mm	?50 mm x 18 mm	?75 mm x 21 mm
Active Detector Area	95.0 mm2	314.2 mm2	1590.4 mm2	314.2 mm2	1590.4 mm2
Input Aperture Size	?11 mm (0.433")	?20 mm (0.79")	?45 mm (1.77")	?20 mm (0.79")	?45 mm (1.77")
Distance to Detector	2 mm (0.08")			2 mm (0.08")
Cable Length	1.5 m (60")			1.5 m (60")
Connector	BNC Male / Sub-D 9-pin Male, Adapter Included			BNC Male / Sub-D 9-pin Male, Adapter Included
Weight	0.1 kg	0.15 kg	0.32 kg	0.15 kg	0.32 kg
Mounting and Accessories
Post	8-32 Mounting Thread, 8-32 and M4 Insulating Adapters Included			8-32 Mounting Thread, 8-32 and M4 Insulating Adapters Included
Cage System Mounting	N/A	Four 4-40 Threaded Holes for 30 mm Cage Systems	N/A	Four 4-40 Threaded Holes for 30 mm Cage Systems	N/A
Aperture Thread	N/A			N/A

Item #	ES308C	ES312C	ES408C	ES412C
Technical Specs
Detector Type	Fast Pyroelectric Energy Sensor
Wavelength Range	185 nm - 25 μm		185 nm - 2.5 μm
Optical Energy Range	500 μJ - 1 J	100 μJ - 1 J	100 μJ - 1 J	50 μJ - 500 mJ
Max Repetition Rate (@ 1 MΩ Load)	1 kHz	250 Hz	10 kHz	2 kHz
Max Power Density (Pulse Width)	8 MW/cm2 (10 ns Pulse)		5 MW/cm2 (10 ns Pulse)
Max Pulse Energy Density (Pulse Width)	80 mJ/cm2 (10 ns Pulse)		50 mJ/cm2 (10 ns Pulse)
Max Average Power	0.5 W		0.5 W
Resolution	5 μJ	1 μJ	1 μJ
Linearity	±1%		±1%
Measurement Uncertainty	±5% @ 185 nm - 25 μm		±5% @ 185 nm - 2.5 μm
Thermal Time Constant	0.6 ms	2 ms	0.07 ms	0.5 ms

General Information
Coating	Black Broadband		Metal
Cooling	Convection
Compatible Consoles	PM100D, PM400 and PM5020		PM5020	PM100D, PM400 and PM5020
Compatible Interfaces	PM103, PM103A, PM103E, PM103U, and PM100USB		PM103, PM103A, PM103E, and PM103U	PM103, PM103A, PM103E, PM103U, and PM100USB
Mechanical Specs
Sensor Dimensionsa	?38 mm x 15 mm	?38 mm x 15 mm	?38 mm x 15 mm	?38 mm x 15 mm
Active Detector Area	50.3 mm2	113.1 mm2	50.3 mm2	113.1 mm2
Input Aperture Size	?8 mm (0.31")	?12 mm (0.47")	?8 mm (0.31")	?12 mm (0.47")
Distance to Detector	2 mm (0.08")
Cable Length	1.5 m (60")
Connector	BNC Male / DE-9 Male, Adapter Included
Weight	0.09 kg
Mounting and Accessories
Post	8-32 and M4 Combi Mounting Thread
Cage System Mounting	N/A
Aperture Thread	External SM1 (1.035"-40) Thread Thread Depth: 3.0 mm (0.12")
